ME35 series PCD ball end milling cutter (Composite)
ME35 series PCD ball end milling cutter (Composite) is a universal PCD ball-end mill designed for machining a wide range of non-ferrous metals and composite materials, including: • Aluminum and its alloys • Copper and its alloys • Fiber-metal composites • Glass • Engineering ceramics • Engineering plastics • Stone and wood
Order NowFor Customization
Product Details
Key highlights include:
·
PCD (polycrystalline diamond) cutting
edges offering extremely high
wear resistance and long tool life, making them ideal for abrasive and
wear-intensive materials.
·
Ball-nose geometry perfect for 3D surface finishing,
complex contoured surfaces, and smooth transitions.
·
Likely
shares advanced design traits found in sister models like the ME31 or ME36,
such as:
o Sharp, light-cutting “JD Diamond TOOL"
o
Medium-grained
PCD with balanced wear and fracture resistance
o
Center-through cutting edge for axial feed-like drilling action
o
Small R angle & chamfer at edges, enhancing durability
o Optimized chip groove design for dynamic balance and smoother cutting
Summary Table
|
Aspect |
Details |
|
Series |
ME35 – PCD
universal ball-end milling cutter (Composite) |
|
Material Suitability |
Non-ferrous metals,
composites, ceramics, plastics, wood, stone |
|
Geometry |
Ball-nose (3D
contouring, finishing) |
|
PCD Features |
High wear
resistance, excellent tool life, superior surface quality |
|
Advanced Design |
Center cutting,
balanced edges, chamfers, vibration-reducing features |
|
Customization |
Available from JD DIAMOND TOOLS |
|
Performance vs Carbide |
Higher cutting
parameters and longer life |
|
Applications |
3D finishing,
composite machining, mold surfaces, precision contouring |
|
Supplier Info |
Available via JD DIAMOND TOOLS |
Customer Ratings
5.0/5
Based on 2 reviews
Customization product
I’ve been using this product for several months now, and it stands out as one of the best tools for customization in manufacturing. Whether you're working with metal, plastic, or composites, this tool adapts easily to different workflows and materials. Highly recommended for teams looking for precision, efficiency, and customization all in one.
Frequently Asked Questions
1.
What is the ME35 series used for?
PCD ball end mills optimized for composite and non-ferrous machining, offering
universal application across a variety of materials.
2.
What materials are it suited for?
Tailored for non-ferrous metals like aluminum and copper, composites, ceramics,
plastics, glass, wood, and stone.
3.
What's the key advantage of PCD in these
tools?
Exceptional wear resistance, superior service life, and high-performance
cutting in abrasive conditions.
4.
Why use a ball-nose (ball end) profile?
Enables smooth 3D machining, great for complex contours and finishing, allowing
for finer surface quality and precision.
5.
Does it support axial plunge
(drilling-like) cutting?
Yes—the ME31 sibling features center-through cutting edges enabling axial
feeds; ME35 likely shares this capability.
6.
How is vibration handled?
Design includes features like small R angles, chamfers, and balanced geometry
for reduced vibration and enhanced stability.
7.
Can the tool be customized?
Yes—JD Diamond Tool offers customization services, likely available for the ME35
series too.
8.
Is its performance better than coated
carbide tools?
Yes—the PCD construction allows for higher cutting parameters, better
reliability, and longer tool life compared to traditional tools.
9.
Typical applications?
Complex 3D surfacing, finishing of composites or non-ferrous parts, mold and
aerospace component machining, plus pocketing and contour operations in
abrasive media.
10. Where
to get more details or a quote?
Visit the JD DIAMOND TOOLS website and request specs or
contact their sales team for technical sheets.
