ME35 series PCD ball end milling cutter (Small diameter)
The ME35 series PCD ball end milling cutter (Small diameter) is a variant within JD Diamond's ME35 family, tailored for precision and flexibility while machining smaller features. Like its counterparts, it's a universal PCD ball-end mill ideal for a broad range of materials, specifically: • Non-ferrous metals (e.g. aluminum and its alloys, copper) • Fiber-metal composites • Glass • Engineering ceramics • Engineering plastics • Stone and wood
Order NowFor Customization
Product Details
Though detailed specs for the "Small diameter" variant aren't explicitly listed, it shares these likely features with other ME-series models such as ME31:
· Z-edge technology: Sharp and light cutting edges optimized for high-speed milling
· Medium-grained PCD: Balancing wear resistance and toughness for long tool life
· Center-through cutting edges: Enabling efficient axial plunge cutting similar to drilling
·
Edge features: Small
R-angle and chamfer designed to enhance durability
· Optimized groove and dynamic balance: Supports stability and high-speed operation
· Superior performance over coated tools: Supports higher cutting parameters, more reliable processes, and longer tool life
Customization options: Likely available to suit specific diameters and applications
Quick Summary Table
|
Feature |
Details |
|
Series Variant |
ME35 – PCD ball-end mill, small diameter version |
|
Material Compatibility |
Non-ferrous metals, composites, ceramics, plastics, stone,
wood |
|
Geometry |
Ball-end for precision 3D finishing |
|
Key Tech Features |
Z-edge cutting, medium PCD grain, center-through edge
design, chamfers, optimized groove |
|
Dynamic Design |
Balanced for high-speed stability and reduced vibration |
|
Customization |
Available—diameter and geometry options customizable |
|
Benefits vs Carbide Tools |
Higher speeds, longer tool life, superior surface finish |
|
Ideal Uses |
Small-feature machining, mold finishing, precision 3D
contouring |
|
Supplier Info |
Procurement and specs via JD Diamond official product pages |
Customer Ratings
5.0/5
Based on 2 reviews
Customization product
I’ve been using this product for several months now, and it stands out as one of the best tools for customization in manufacturing. Whether you're working with metal, plastic, or composites, this tool adapts easily to different workflows and materials. Highly recommended for teams looking for precision, efficiency, and customization all in one.
Frequently Asked Questions
1. What
is the ME35 Small Diameter variant?
It’s a PCD ball-end milling cutter optimized for machining fine, small-diameter
features in a variety of materials.
2. Which
materials is it suited for?
Suited for non-ferrous metals, composites, ceramics, engineering plastics,
stone, and wood.
3. What
advantages does PCD offer?
Exceptional wear resistance, higher speeds, longer tool life, and better
surface finish compared with conventional coatings.
4. Why
choose a ball-end geometry in small diameters?
Excellent for precision 3D contouring and finishing of complex surfaces with
high accuracy.
5.
Does it support plunge (axial) cutting?
Yes—from its design with center-through edge geometry, it enables axial feed
similar to drilling.
6. How
does its design improve stability and durability?
Optimized edge features such as R-angle, chamfer, and groove design reduce
vibration and enhance dynamic balance.
7. Is
it customizable for specific small diameters?
Likely—customization is offered in the ME series. Contact JD Diamond for
options.
8. How
does it perform compared to coated carbide tools?
Delivers better reliability, supports higher feed speeds, and significantly
increases tool lifespan.
9. What
typical applications suit this tool?
Ideal for finishing of intricate 3D surfaces, micromachining in aerospace, mold
industries, precision components, and small-feature pockets.
10. Where
to get product specs or purchase?
Visit the JD Diamond Tool site for requests or reach out to their sales team for
detailed datasheets and customization support.
